The Oryx Handbook of Iranian Ballistic Missiles and Artillery Rockets

Notes:

- If several configurations of a missile, rocket or launcher are known, they are added as such.

- The part within the apostrophes refers to other designations or an unofficial designation.

- When available, the date of inception and range are added. As this list mostly relies on data reported by Iranian sources, the date of inception and range should be used as a rough indication rather than a precise estimate.

Although a great deal of effort has been put into ensuring the accuracy of this list, any updates or corrections to this list are most welcome.

(Click on the equipment to get a picture of them in Iranian service)

Short-Range Ballistic Missiles (SRBM)

• Tondar-69 [1992] [Range: 150km]
• Fateh-110 1st Gen. ''Fateh-110A'' [2002] [Range: 200km] (Not believed to have entered mass production)
• Fateh-110B ''2nd Gen.'' [2004] [Range: 250km] Five launcher configurations: (2) (3) (4) (5)
• M-600 ''Tishreen'' [2004] [Range: 250km] (Fateh-110B developed for Syria)
• Fateh-110C ''3rd Gen.'' [2010] [Range: 300km] Two launcher configurations: (2)
• Fateh-110D ''4th Gen.'' [2012] [Range: 300km]
• R-17 Elbrus ''SS-1 Scud-B'' [Range: 300km] (Likely to have been decommissioned)
• Hwasong-5 [Range: 300km] (Likely to have been decommissioned)
• Shahab-1 [1988] [Range: 350km]
• Shahab-2 [1998] [Range: 500km] Four launcher configurations: (2) (3) (4, silo launched)
• Fateh-313 [2015] [Range: 500km] Three launcher configurations: (2) (3, dual launcher)
• Zolfaghar ''Zulfiqar'' [2016] [Range: 750km] Five launcher configurations: (2) (3) (4, dual launcher) (5, dual launcher)
• Fateh Mobin [2018] (Guidance kit that can be retrofitted to the entire Fateh lineage. Uses an infrared seeker)
• Zelzal 307 ''Raad 307'' [2014] [Range: 300km] Two launcher configurations: (2, triple launcher) (Fitted with a multiple reentry vehicle payloads Two configurations (2))
• Qiam-1 ''Qiyam-1 or Qaem-1'' [2010] [Range: ~800km] Two launcher configurations: (2, underground launching unit)
• Qiam-2 ''Qiyam-2 or Qaem-2'' [2010] [Range: ~800km]
• Borkan-H2 (Qiam-1 developed for Houthi militants in Yemen)
• Borkan-3 (Qiam-1 developed for Houthi militants in Yemen)



Medium-Range Ballistic Missiles (MRBM)

• Dezful [2019] [Range: 1000km] Two launcher configurations: (2, dual launcher)
• Emad [2015] [Range: 2000km]
• Ghadr-1 ''Ghadr-110 or Shahab-3B''
• Ghadr-F [Range: ~2000km]
• Ghadr-H Two configurations: (2)
• Khorramshahr-1 [2017] [Range: 2000km] Two configurations: (2)
• Khorramshahr-2 [2019] [Range: 2000km]
• Sejjil-1 ''Sejil-1, Ashura, Ashoura or Ghadr-110'' [2007] [Range: ~2000km]
• Sejjil-2 ''Sejil-2, Ashura or Ashoura'' [2009] [Range: 2000km]
• Shahab-3 ''Shahab-3A/M or Ghadr-101'' Three configurations: (2, triconic warhead) (3, biconic warhead) Three launcher configurations (2) (3, silo launched)

Anti-Ship Ballistic Missiles (ASBM)

• Khalij Fars [2011] [Range: 300km] Five launcher configurations: (2) (3) (4, dual launcher) (5, triple launcher) (Uses an electro-optical/infrared seeker)
• Hormuz-2 [2014] [Range: 300km] Three launcher configurations: (2, dual launcher) (3, dual launcher) (Uses an active radar-homing seeker)



Anti-Radiation Ballistic Missiles (ARBM)

• Hormuz-1 [2014] [Range: 300km] Three launcher configurations: (2, dual launcher) (3, dual launcher) (Uses a passive radar-homing seeker)



Ballistic Missiles - Documented But Not Yet Seen

• Ghadr-S ''Qadr-S'' (Documented by a few sources, not yet seen)
• Oghab (Documented by a few sources, not yet seen)
• Samen ''Ghadr-101 or M-9'' (Documented by a few sources, not yet seen)
• Sejjil-3 (Documented by a few sources, not yet seen)
• Shahab-3C (Documented by a few sources, not yet seen)
• Shahab-3D (Documented by a few sources, not yet seen)
• Shahab-4 ''IRIS'' (Documented by a few sources, not yet seen)
• Shahab-5 (Documented by a few sources, not yet seen)
• Shahab-6 (Documented by a few sources, not yet seen)
• Project Kowsar ''Koussar'' (Documented by a few sources, not yet seen)
• Meshkat (Documented by a few sources, not yet seen)
• Samid (Documented by a few sources, not yet seen)
• Yasser (Documented by a few sources, not yet seen)

Artillery Rockets

• Shahin-1 [Range: 13km]
• Shahin-2 [Range: 20km]
• 9K52 Luna-M ''FROG-7'' [70km] (Likely to have been decommissioned)
• Fajr-5 Prototype: (1)
• Naze'at-6H ''Mushak'' [Range: 100km] Two launcher configurations: (2)
• Naze'at-10H ''Mushak'' [Range: 130km] Three launcher configurations: (2) (3)
• Zelzal-1 ''Mushak-120'' [1990] [Range: 160km] Three launcher configurations: (2) (3)
• Zelzal-2 ''Mushak-200'' [1998] [Range: 220km] Five launcher configurations: (2) (3) (4) (5)
• Maysalun [Range: 220km] (Zelzal-2 developed for Syria)
• Zelzal-3 [2007] [Range: 200km] Two launcher configurations: (2, triple launcher)
• Zelzal-3B [Range: 250km]
• Zelzal-1A ''Mushak-160'' (Documented by a few sources, not yet seen)
• Unknown Artillery Rocket



Artillery Rockets - Documented But Not Yet Seen

• Naze'at-4 ''Mushak'' (Documented by a few sources, not yet seen)
• Naze'at-5 ''Mushak'' (Documented by a few sources, not yet seen)
• Zelzal-1A ''Mushak-160'' (Documented by a few sources, not yet seen)



Cruise Missiles

• Soumar [2015]
• Hoveyzeh [2019] [Range: 1350km]
• Quds [2018] (Supplied to Houthi militants in Yemen. Used in the 2019 Abqaiq–Khurais attack on Saudi Arabia)
• Meshkat [2012] (Did not enter production)
• Ya Ali (Documented by sources as used in the surface-to-surface role, not yet seen in this configuration)
